Name: Fixed Ammonia (NH3) Gas Detector (0-100ppm)
SKU: 304571

Product Details ＋

The Fixed Ammonia NH3 Gas Detector is designed to protect individuals near toxic and combustible gases, refrigerants, or oxygen in commercial and industrial applications. This fixed gas safety monitor measures NH3 levels between 0-100ppm and detects hazards in order to protect facilities from overexposure.

Fixed ammonia gas detectors are critical in pharmaceutical, petrochemical, poultry, indoor agriculture, and research applications - or anywhere NH3 is being used, stored, or produced.

Features

Modular easy-to-use design
1-3 gas sensor capabilities
3 configurable relays
2 sensors max may be different sensors of the SC2 series, max 3 of them analog with 4-20 mA signals
Custom configuration dependent upon location and application
Warning buzzer/LED alarm, fault operation option
Compatible with a wide range of BMS
Protocol for DGC-06 or Modbus protocol
Operating voltage input 100-240 VAC or 24VDC

Specifications

Measurement Range: 0-100ppm
Additional Ranges Available on request:
- 0-300ppm, 0-500ppm, 0-1,000ppm, 0-5,000ppm
Gas Type: Ammonia
Housing Type C/E: Polycarbonate
Installation: Wall Mounted
Knockouts for Cable Entry: Standard 6x M20/25
Ingress Protection: IP65
Temperature Range: -13°F to 140°F (-30°C to 50°C)
Humidity Range: 15-90% RH non-condensing
Storage Temperature: -4°F to 149°F (0° to 20°C)
Power Supply: 100-240 VAC or 24VDC
Power Consumption: 24 V DC | Max. 60 mA (1.5 VA), w/ sensor, w/o WAO
Alarm Relay (3): 5 A Dry Contact Configurable
Transistor Output (2): 24 V DC/0.1 A
Analog Input (2/3): 4-20mA, overload and short-circuit proof, input resistance 130 proportional, overload and short-circuit proof, load ≤ 500 4–20 mA = measuring range
Analog Output Signal (1):
- 2.4–< 4 mA = tolerable under range
- 20–21.2 mA = tolerable over range
- ≥ 21,2 mA= error over range
- ≤ 2,0 mA = fault
Dimensions: 5.12 x 5.12 x 2.95 in. (130 x 130 x 75 mm)
Weight: 1.32 lbs. (0.6 kg)
