Product Details
＋
| Product Attribute | Attribute Value |
|---|---|
| Application | Industrial control circuits and components, instrumentation, drives, CNC machinery, equipment for food industry, microprocessor circuits, analog circuits, noise sensitive circuitry and sensors |
| Configuration | Open Frame |
| Current Rating | 1.2 A |
| Frequency | 47 to 63 Hz |
| Input Voltage | 100 VAC ; 110 VAC ; 115 VAC ; 120 VAC ; 127 VAC ; 190 VAC ; 200 VAC ; 220 VAC ; 230 VAC ; 240 VAC |
| Line Regulation | 0.05 % |
| Load Regulation | 0.05 % |
| Mounting Type | Panel Mount |
| Number of Outputs | 1 Output |
| Operating Temperature | 0 to 50 °C |
| Operation | Linear |
| Output Current | 1.2 A |
| Output Power | 28.8 W |
| Output Voltage | 24 VDC |
| Primary Type | AC-DC |
| Product Header | Silver Line Series Linear Power Supply |
| Regulation, Line | 0.05 % |
| Series | |
| Special Features | Remote Sense |
| Standards | UL Recognized, CS Certified, CE Approved |
| Temperature Coefficient | 0.01% (Typ.) |
| Type | Embedded |
| Voltage, Input Range | 100-240 VAC |
Overview
Silverline Series
Features and Benefits:
