Please note these batteries are made to order with a lead time of 3 weeks before delivery. Please confirm stock before purchase.

System Features

• It’s a flexible solution for both small configurations and mid-sized configurations.
• It supports both parallel connections and CAN communications.
• A modular design.
• Very easy to install.
• A universal Wall-mounted system.

Applications

• Residential PV Installations for household energy demands.
• Residential and commercial UPS systems.
• Used with the addition of an external battery inverter
• Off-Grid energy system.
• We use the standard SS4037 battery all over the African market for energy storage applications.
• We produce the battery with the world-leading LiFeP04 technology.

Battery Features

• Excellent safety.
• High-temperature performance.
• Long life cycle.
• High energy density.
• Stable discharge platform.
• High charge & discharge rate.
• Highly efficient.

Specifications

• Model: SS4074.
• Battery Type: Lithium Iron Phosphate (LiFeP04).
• Rated Battery Capacity: 8kWh.
• Output Power: Max 5kW.
• Usable battery energy @0.3C: 7.4 kWh.
• Nominal voltage: 51.2V.
• Number of battery modules: 1 module.
• Weight of unit: 76 kg.
• Operational voltage: 44.8-55.6 Vdc.
• Communication: CAN.
• Dimensions {mm): Width 640 x depth 200 x height 630.
• Battery cycle life ( 25°Cl): > 4000.
• Charging efficiency: 99%.
• Operational temperature: -5 °C to 50 °C.
• Storage duration: 6 months at 25 °C Safe standard.
• Compliance: IEC 62619 I UN 38.3 I UL1642.
• Cell Certificate: TUV I CE I RCM I UL1642.
