Product Details
＋
| Product Attribute | Attribute Value |
|---|---|
| Alternate Mfr Part Number | T4406700 |
| Body Style | Cylindrical |
| Current Consumption | 100 mA (Max.) |
| Current, Switching | 100 mA |
| Dimensions | 2.047" L |
| Frequency, Switching | 2 kHz |
| Housing Material | CPB |
| IP Rating | IP67 |
| Maximum Operating Temperature | 70 C |
| Measurement Range | 4 mm |
| Minimum Operating Temperature | -25 C |
| Mounting Type | M12 Threaded |
| Operating Temperature, Maximum | 70 C |
| Operating Temperature, Minimum | -25 C |
| Output | NO |
| Primary Type | Inductive Proximity Sensors |
| Series | |
| Standards | IP 67 Protection |
| Supply Voltage | 65 VDC |
| Termination | M12, 2 Pin |
Overview
TURCK inductive proximity sensors are manufactured with shielded coil, designated by “Bi” in the part number, and a non-shielded coil, designated by “Ni” in the part number. Embedded (shielded) units may be safely flush-mounted in metal. Non-embeddable (non-shielded) units require a metal free area around the sensing face. Because of possible interference of the electromagnetic fields generated by the oscillators, minimum spacing is required between adjacent or opposing sensors.
